With the new series of Circulation pumps for Domestic Hot Water Systems TacoFlow2 PURE, TacoFlow2 PURE PLUS & TacoFlow2 PURE C from TACONOVA, you can reduce power consumption by up to 80% (PURE PLUS) compared to a standard circulation pump, whilst maintaining the same hydraulic output, since they adjust their operation according to the temperature of the returned water, as well as based on the schedule.
TACOFLOW2 PURE & TACOFLOW2 PURE PLUS
TACOFLOW2 PURE
TACOFLOW2 PURE PLUS
The rotating parts of the motor run inside the pumped medium. This ensures the lubrication of the motor and the rotating parts.
Circulation pumps for Domestic Hot Water Systems TacoFlow2 PURE & TacoFlow2 PURE PLUS can be optimally adapted to the system by selecting the most appropriate of the three available curves. The circulation pump is equipped with anti-blocking protection and can be installed both horizontally or vertically.
ADVANTAGES:
- Efficient output setting with three constant-pressure curves
- Ceramic shaft
- Media temperature range from +5 °C to +65 °C
- Contact sensor for temperature control and setting of the circulation temperature limit, usually 43°C (PLUS version)
- Integrated timer for individual seven-day programming
- Display LCD (PLUS version)
- Maximum flow rate: 650 lt/h
- Maximum manometer: 1,4 m
TACOFLOW2 PURE C
Domestic Hot Water circulation pumps for domestic hot water systems TACOFLOW2 PURE C is suitable for DHW systems in residential and commercial buildings. The pump can be installed both horizontally or vertically. The arrow indicating the medium‘s flow direction must be observed. The TacoFlow2 PURE C (Composite) is driven by permanent-magnet synchronous motors. These innovative motors achieve a high efficiency at low operating costs.
- Efficient throughput setting with fixed Min-Max speed.
- Media temperature range from +2 °C to +95 °C
- A colour LED indicates the current operating state
- Maximum flow rate: 2,4 m3/h
- Maximum manometer: 3,8 m
